Product Introduction of Special-shaped Wire Drawing Dies

Product Function

The special-shaped wire drawing die can accurately draw various metal thick wires into thin wires with specific cross-sections. The cross-section of the incoming wire is unrestricted, and the cross-section of the outgoing wire is non-circular. The die needs to be used in sets. When the cross-section of the finished wire is in some simple shapes, it can be directly equipped with a fixed-ratio wire drawing machine. Some simple-hole die molds can adopt nano-diamond composite coatings.

Manufacturing Features

Nano-diamond Composite Coating

Due to the limitation of the die hole shape, some simple-hole dies can be equipped with nano-diamond composite coatings, while those with complex shapes or small turning angles cannot. For details, please contact our sales staff.

Application Features

Precise and Reasonable Die Hole

With the help of computer-aided design, manufacturing, and inspection, the die hole gradient of the die is precise and reasonable.

Unrestricted Die Hole Design

It can make wire drawing dies with any die hole shape to meet diverse production needs.

Benefits for Users

Strong Processing Flexibility

It can draw metal wires with any cross-section into the specified shape to meet complex processing requirements.

Cost Saving

When the cross-section of the finished wire is in some simple shapes, a fixed-ratio wire drawing machine can be used, reducing costs.

Dual Optimization of Efficiency and Cost (Coated Dies)

Coated dies have a long service life and unchanged hole diameters, improving efficiency and saving materials. Water lubrication can be used for drawing non-ferrous metals, reducing lubrication costs.
